¾” PEX conduit

All Products Shielding ¾” PEX conduit
Product Highlights
  • Waterproof and rugged
  • Up to 2000 ft runs with transition fittings
  • Include flex conduit length for the above ground portion for easier install and UV resistance
  • Easy snap on 90 degree trainers for routing in the field

Overview

Our most commonly used shielding, PEX provides a flexible and workable layer around our DTCs, enhancing abrasion and crush resistance and providing the capacity to direct-bury. Adapter fittings allow transitions to bare cable lead, HDPE, or directly into panel boxes.

Specification

Installation

● Ready to install. Suitable for direct burial

Nominal Diameter

● ¾” (1.905cm)

Average OD

● 0.875”(2.22cm) ± 0.004”(0.010cm)

Wall thickness

● 0.1in ± 0.004in (0.254cm ± 0.01016)

Weight

● 0.10 lb/ft (0.149kg/m)

Degree of cross-linking

● 70-79%

Thermal conductivity

● 0.24 BTU/(hr ft °F) (0.41 W/(m°K))

Linear expansion

● 9.33 X10^-4 in/(ft°F) @ 68° F

Working range

● -40° F to 200° F (-40° C to 93° C)
